Generator : Ring safe
| Kind of M/C | GENERATOR ( 150 KVA.) |
| Inventory No. | 150-22 |
| Serial No. | 38896239 |
| Dimention (W x L x H) | 165x375x240 cm. |
| Purchase Date | |
| Engine No. | Komatsu 26494141 |
| Trade Name | DENYO DCA 150 ESK |
| Weight (2 Jan 14Kg.) | 4,000 Kg. |
| Specification | ||||||
|---|---|---|---|---|---|---|
| ALTERNATOR | DCA-150ES | |||||
| Frequency Hz | 50 | 60 | ||||
| Output Rating (kVA) | Continuous | 125 | 150 | |||
| Standby | 138 | 165 | ||||
| No.of Phases | 3-Phase,4-Wire | |||||
| Rated Voltage V | 2 Dual Voltage | |||||
| Power Factor | 0.8 (Lagging) | |||||
| Voltage Regulation % | Within ± 0.5 | |||||
| Excitation | Brushless,Rotating Exciter (With A.V.R.) | |||||
| Insulation | Class F | |||||
| ENGINE | Komatsu | |||||
| MaKe&Model | SAA6D102E-2-D | |||||
| Type | Inlined,Direct Injected,Turbocharged,Aftercooled | |||||
| Output Rating | PS/rpm | 153/1500 | 183/1800 | |||
|
kW/min 1 |
113/1500 | 135/1800 | ||||
| No.of Cylinders-Bore X Stroke mm | 6-102 X 120 | |||||
| Piston Displacement L | 5.88 | |||||
| Fuel | ASTM No.2 Diesel Fuel or Equivalent | |||||
| Fuel Consumption L/h | 20.6 | 25 | ||||
| Lube Oil Sump Capacity L | 22 | |||||
| Coolant Capacity L | 28.4 | |||||
| Battery X Quantity | 95E41R X 2 | |||||
| Fuel Tank Capacity L | 250 | |||||
