Generator : Ring safe
Kind of M/C | GENERATOR ( 300 KVA. ) |
Inventory No. | 300-11 |
Serial No. | 1342999 |
Dimention (W x L x H) | 205 x 420 x 280 cm. |
Purchase Date | |
Engine No. | KOMATSU SA6D125E-2-A |
Trade Name | DENYO 300 KVA. |
Weight (2 Jan 14Kg.) | 6,500 Kg. |
Specification | |||||||
---|---|---|---|---|---|---|---|
Engine No. | : | KOMATSU SA6D125E-2-A | |||||
Trade Name | : | DENYO 300 KVA. | |||||
Weight ( Kg. ) | : | 6,500 Kg. | |||||
ALTERNATOR | DCA-300SP | ||||||
Frequency Hz | 50 | 60 | |||||
Output Rating (kVA) | Continuous | 270 | 300 | ||||
Standby | 297 | 330 | |||||
No.of Phases | 3-Phase,4-Wire | ||||||
Rated Voltage V | 2 Dual Voltage | ||||||
Power Factor | 0.8 (Lagging) | ||||||
Voltage Regulation % | Within ± 0.5 | ||||||
Excitation | Brushless,Rotating Exciter (With A.V.R.) | ||||||
Insulation | Class F | ||||||
ENGINE | Komatsu | ||||||
MaKe&Model | SA6D125E-2-A | ||||||
Type | Inlined,Direct Injected,Turbocharged,Aftercooled | ||||||
Output Rating | PS/rpm | 316/1500 | 350/1800 | ||||
kW/min-1 | 232/1500 | 257/1800 | |||||
No.of Cylinders-Bore X Stroke mm | 6-125 X 150 | ||||||
Piston Displacement L | 11.04 | ||||||
Fuel | ASTM No.2 Diesel Fuel or Equivalent | ||||||
Fuel Consumption L/h | 43.6 | 50 | |||||
Lube Oil Sump Capacity L | 62 | ||||||
Coolant Capacity L | 37 | ||||||
Battery X Quantity | 145G51 X 2 | ||||||
Fuel Tank Capacity L | 490 |
